Working principle and applicatiom:
The JSI-748DA series of quartz electronic sealed timers have novel structure, dexterity, high precision, stable and reliable performance, long life, wide adaptation to the environment, low price and convenient use. It is widely used in engineering machinery, engineering vehicles, agricultural machinery, generators, air compressors, water pumps, cranes, cranes, various types of automobiles, etc.
Main technical parameters:
|
Timing range |
0~99999.9 (hour) |
|
Timing accuracy |
±0.01 |
|
Zero reset device |
No reset |
|
Voltage type |
12-36V (AC and DC universal), 100-250V 10-80V |
|
Operating temperature |
-10℃~50℃ |
