BTA41-800BW 40A TRIAC
Description:
The BTA41-800BW triac is suitable for general purpose AC switching. It can be used as an ON/OFF function in applications such as heating regulation,induction motor starting circuits, for phase control operation in light dimmers,motor speed controllers. BTA41-800BW snubberless triac is especially recommened for use on inductive loads. By using an internal ceramic pad, BTA41-800BW provides a rated insulation voltage of 2500VRMS, compling with UL standards. Package TO-3P is RoHS compliant.
Main Features:
| Symbol | Value | Unit |
| IT(RMS) | 40 | A |
| VDRM/VRRM | 800 | V |
| IGT |/||/||| | 50/50/50 | mA |
